High Quality PTFE Tensile Membrane Canopy . Request a free demo today.
The PTFE membrane is known as "thesix kind of architecture material" afterbrick, stone, concrete, steel and wood. Itis soft, and suitable for various shapes,breaks the limitation like shape and spanof traditional architecture materials.
· High Strong Mechanical Performance
· Superior Fireproof Performance
· Excellent Optical Performance
· Sound Lnsulation Performance
· Superior Acoustic Performance
· Unqiue Self-cleaning Performance
| PTFE tensile membrane | ||||||||||||
| Item | Color | Thickness(mm) | Fabric weight(g/m)±3%6 | TotalWeight(g/㎡) | PTFEcontent(96) | Tensile Strength(N/5cm)±5% | TearStrength(N/5cm)±5%GB/T 25042-B | PeelStrength | Joint StrengthN/5cm≥ | |||
| warp | weft | warp | weft | warp | weft | |||||||
| M601 | white/beige | 0.65±0.05 | 1250±60 | 7000 | 6500 | 400 | 400 | 90 | 7000 | 6500 | ||
| M602 | white/beige | 0.5±0.05 | 468 | 900±45 | 53%6 | 4500 | 4000 | 350 | 350 | 70 | 4500 | 4000 |
| H300 | white/beige | 1.0±0.1 | 740 | 1600±80 | 5596 | 9500 | 8500 | 500 | 500 | 140 | 9500 | 8500 |
| H301 | white/beige | 0.8±0.08 | 677 | 1300±65 | 49.80%6 | 8000 | 7000 | 400 | 400 | 140 | 8000 | 7500 |
| H302 | white/beige | 0.6±0.05 | 487 | 1050±50 | 55.70%6 | 6000 | 5500 | 350 | 350 | 90 | 6000 | 5500 |
| H303 | white/beige | 0.65±0.05 | 580 | 1150±50 | 51.6096 | 7000 | 7000 | 400 | 400 | 120 | 7000 | 7000 |
| T300 | white/beige | 0.35±0.05 | 283 | 500±50 | 4696 | 3000 | 2800 | 160 | 110 | 20 | 3000 | 2800 |
| K600 | beige,very soft | 463 | 700±30 | 4500±300 | 4000±300 | |||||||
| K500 | brown | 680±68 | 3500 | 3000 | ||||||||
| T1200P | 1.1±0.06 | 1000±100 | 3500 | 3200 | 3500 | 3200 | ||||||
(1)PTFE membrane material is a kind of high polymer composite material, has excellent mechanical properties like outstanding patience, good winding strength, and reasonable structure design, is better than the strength of steel. PTFE membrane material construction usually can last more than 50 years.
(2)Self-cleaning with superior performance of non-stick, decades later it still keep white surface as pervious.
(3)As construction period is short, fabric cutting, seam welding, machining, can be made in one factory, which greatly reduce the construction work site and construction time.
